Home > Stainless Steel > Stainless Steel 420 Tubing
Tun Pipes, a well-respected manufacturer and supplier based in Naypyidaw, Myanmar, has built a solid reputation for providing top-notch Stainless Steel 420 Tubing that adheres to international standards for durability and performance. This tubing is celebrated for its remarkable strength and resistance to corrosion, making it perfect for demanding industrial applications. With a keen emphasis on precision engineering, Tun Pipes delivers reliable tubing solutions that cater to a variety of needs in critical sectors. Their unwavering commitment to quality, timely delivery, and customer satisfaction has positioned them as a go-to choice for Stainless Steel 420 Tubing in both domestic and international markets.
Stainless Steel 420 Tubing is primarily made of chromium, with a touch of carbon added to boost its hardness and wear resistance. It showcases impressive mechanical strength, toughness, and moderate resistance to corrosion, particularly when hardened or tempered. This tubing boasts a tensile strength of around 700 MPa and shows good resistance to scaling at elevated temperatures. Thanks to its martensitic structure, Stainless Steel 420 is highly machinable, making it easy to shape into precise forms. Its unique combination of hardness and durability makes it a favored material for mechanical, structural, and industrial applications.
Item | Stainless Steel 420 Tube |
Standard | GB, AISI, ASTM, ASME, EN, BS, DIN, JIS |
Type | Seamless / ERW / Welded / Fabricated / CDW |
Outer Diameter Size | SEAMLESS – 1/2″ NB TO 18″ NB WELDED / ERW- 1″ NB TO 16″ NB EFW – 8″ NB TO 110″ NB |
Form | 420 Round Tubing, 420 Square Tubes, 420 Rectangular Tube, “U” Shape 420 Tubing, 420 Hydraulic Tubes |
Wall Thickness | Schedule 10 To Schedule 160 (3 mm to 100 mm Thickness) |
Length | 01 Meter to 12.5 Meters, Single Random Length, Double Random Length And Customize Size End: Plain End, Beveled End, Treaded |
Delivery Conditions | As Rolled, Formed, Stress Relieved, Annealed, Hardened, Tempered, Cold Draw |
Coating | Electropolish, Mechanical Polish, Satin Finish, Passivated |
Testing | Product Analysis, Transverse Tension Test, Flattening Test, Etching Test, Radiographic Examination, Stabilizing Heat Treatment, Intergranular Corrosion Test, Weld Decay Test, Magnetic Particle Detection, Grain Size Test, NACE 0175, Dual Grade, PWHT (POST WELD HEAT TREATMENT), Flare Test, Bend Test, Hardness Test, Tensile Test etc |
Dimension | All Tubes Is Manufactured and Inspected / Tested to the Relevant standards including ASTM and ASME |
Value Added Services | Draw / Expansion / Machining / Sand Blasting / Shot Blasting / Heat Treatment |
Packaging | Loose / Bundle / Wooden Pallet / Wooden Box / Plastic Cloth Wraps / Plastic End Caps / Beveled Protector |
Material Test Certificate | Manufacturer Test Certificate As Per EN10204 3.1, 3.2 / Laboratory Test Certificate From NABL Approved Lab. / Under Third Party Inspection Agency Like SGS, TUV, DNV, LLOYDS, ABS ETC |
| Grade | C | Mn | Si | P | S | Cr | |
|---|---|---|---|---|---|---|---|
| 420 | Min. max. | 0.15 – | – 1 | – 1 | – 0.040 | – 0.03 | 12.0 14.0 |
| Tempering Temperature (°C) | Tensile Strength (MPa) | Yield Strength 0.2% Proof (MPa) | Elongation (% in 50mm) | Hardness Brinell (HB) | Impact Charpy V (J) |
|---|---|---|---|---|---|
| Annealed * | 655 | 345 | 25 | 241 max | – |
| 204 | 1600 | 1360 | 12 | 444 | 20 |
| 316 | 1580 | 1365 | 14 | 444 | 19 |
| 427 | 1620 | 1420 | 10 | 461 | # |
| 538 | 1305 | 1095 | 15 | 375 | # |
| 593 | 1035 | 810 | 18 | 302 | 22 |
| 650 | 895 | 680 | 20 | 262 | 42 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Choosing Stainless Steel 420 Tubing from Tun Pipes and Tubes ensures high quality and durability, as these pipes offer excellent corrosion resistance and strength. Our commitment to exceptional service and reliable delivery guarantees customer satisfaction across various industrial applications. Our expertise in stainless steel products ensures you receive a top-tier solution tailored to your needs.
Tun Pipes and Tubes, one of the largest suppliers of Stainless Steel 420 Tubing in Naypyidaw, Myanmar, offers a comprehensive range of high-quality pipes and tubes suitable for various industrial applications. Their extensive inventory and commitment to exceptional service make them a go-to choice for stainless steel products in the region.
Yes, we offer custom sizes for Stainless Steel 420 Tubing to meet your specific requirements. Our team at Tun Pipes and Tubes is committed to providing tailored solutions for all your Piping & tubing needs. For more details, contact us at sales@tunpipes.com.
You’ll find Stainless Steel 420 Tubing widely used in industries that demand strength, wear resistance, and durability. It’s commonly found in the production of surgical instruments, automotive parts, pump shafts, and valves, all thanks to its hardness and corrosion-resistant qualities. In the oil, gas, and petrochemical sectors, it’s utilized for tubing that must withstand tough environments. Moreover, it’s also employed in aerospace, defense, and marine industries where high-performance materials are crucial. Its ability to undergo heat treatment and polishing further enhances its appeal for decorative and architectural uses, ensuring that it not only performs well but also looks great in various projects.
